Seems like AKLLA have updated the details on their imaginatively named A4-atx. But still no overall dimensions
Overall dimensions: ?
CPU heatsink height: 76mm
GPU support: 330mm
I didn't see the A4s mentioned either so here it is. More details available on this one.
Overall dimensions: 33.5x15.5x20cm = 10.36L
CPU heatsink height: 68mm
GPU support: 330mm, 58mm width
2.5" hard drives: 2x
New case called the A387 showed up
Overall dimensions: 21.5x18x10cm = 3.87L
CPU heatsink height: 40mm
GPU support: 175mm
2.5" hard drives: 2x
WANDU also appear to be new with two cases:
M1
Vertical format with mATX motherboard support (24.5x24.5cm)
Overall dimensions: 25.5x15x32.5cm = 12.4L
CPU heatsink height: 131mm
GPU support: 250mm, 130mm height
2.5" hard drives: 4x at most
3.5" hard drives: 1x (will be interfered with SFX-L sized PSU)
Fans: 2x 9025 top, 1x 9025 rear, 1x 9025 bottom
PSU: SFX/SFX-L
L1
Vertical format again with SFX PSU and no video card support. Very odd indeed. Base is detachable. Also odd is the power button, which is at the bottom of the front.
Overall dimensions: 18.5x7.5x31cm = 4.3L
CPU heatsink height: 55mm
2.5" hard drives: 2x at most
PSU: SFX
New seller called ZIKIM has showed up. But very new and no feedback yet. The designs look pretty cool though
